PFW5, Digital Flow Switch for Water, High Temperature Flow

The PFW digital flow switch for water is available in either an integrated or remote style unit. It is selectable from instant flow or integrated flow. The flow rating can be set at 2 points individually. Series PFW has a waterproof construction (equivalent to IP65). The LED readout is clear and easy to see.

• Remote type display unit, digital flow switch
• For high temperature fluid: 0° to 90°C
• Able to control cooling water used in CVD/PVD
  processes and metal die casting
• 3 different flow rates: up to 4L, 16L and 40L
• IP65 enclosure
• Port sizes: 3/8, 1/2, 3/4

Configuration Options

Select Product Options

	Select values from the drop down lists or make appropriate selections to configure the part number.
Flow Range	-- Pick an Option -- 04 (0.5~4L/min) 20 (2~16 l/min) 40 (5~40 l/min)
Thread	-- Pick an Option -- Rc F (G) N (NPT)
Port Size	-- Pick an Option -- 03 [3/8 (PFW504T, PFW520T)] 04 [1/2 (PFW520T, PFW540T)] 06 [3/4 (PFW540T)]
Wiring Specification	-- Pick an Option -- Lead Wire 3m w/Connector N (w/o Lead Wire)
Output Specification	-- Pick an Option -- 1 (Pulse Output +1~5V) 2 (Pulse Output +4~20mA) Pulse Output Only
	Options in: Gray are not compatible with other selected option value. Red conflict with another selected option value. Amber are not recommended.
